8kVA Hyundai Diesel Generator GHD6400E Mine Spec
8kVA Hyundai Diesel Generator GHD6400E Mine Spec
5.0 store rating, 100 Google reviews
- Single phase
GST included. Why it's under RRP
Free delivery
Australia-wide
Check delivery to your postcode:
Allow up to 10 business days for dispatch. We email your tracking once it's dispatched.
Shipped from our store or direct from the supplier warehouse closest to you.
Add delivery instructions (optional)
These go to the warehouse and the driver with your order.
Secure checkout
Couldn't load pickup availability
Unsure if this is the right generator?
Our size calculator works out the kVA you need from your amps, watts, motor or welder.
- Authorised Genelite Master Dealer
- Full manufacturer warranty
- Advice before you buy: 07 4728 2796 or send a message
- 100 Google reviews, rated 5.0 out of 5
The Hyundai GHD6400E Mine Spec is the mine spec build of the 8kVA (6.4kW) single phase GHD6400E diesel generator, powered by the Hyundai CP192FE diesel engine. Its 25 litre fuel tank gives up to 14 hours at 75% load, and it is rated for standby duty only.
Key features
- Mine spec build: the variant of the GHD6400E specified for mining customers.
- 8kVA / 6.4kW output: the highest output in the single phase GHD line.
- 25 litre fuel tank: five times the standard GHD6400E tank, for long intervals between refuels.
- Up to 14 hours at 75% load: covers a full shift and more at a working load.
- Hyundai CP192FE diesel engine: common across the GHD range for consistent parts and servicing.
- Measured at 80 dBA at 7 m: a published noise figure for site planning.
Operating data: a 25 litre tank and 14 hours at 75% load works out to roughly 1.8 litres of diesel per hour at that load. At its 6.4kW figure the generator supplies roughly 26.7 amps at 240 V. Noise is rated at 80 dBA at 7 m. Output is single phase.
What it will run
With 6.4kW to work with, the GHD6400E Mine Spec typically runs site lighting, crib room appliances used in turn, chargers, and a welder, larger compressor or concrete mixer within its rating. Motor loads draw a surge at start-up, so start the largest first and leave headroom. Check the rating plate on each item and keep the combined running load within 6.4kW.
The GHD6400E Mine Spec suits mining and resources sites that call for a mine spec unit, contractors' compounds and exploration camps. Its long-range tank also makes it a strong option for farm backup, remote infrastructure and home backup through extended outages.
Standby use only. It is built for standby use and is not rated for prime or continuous duty.
Key specifications
- Duty rating: Standby only, not rated for prime or continuous power
- Power output: 6.4kW / 8kVA
- Engine: Hyundai CP192FE
- Phase: Single phase
- Fuel tank: 25L
- Run time: 14 HR @ 75% LOAD
- Noise level: 80 dBA @ 7M
- Weight: 75 kg
- Dimensions (L x W x H): 87 x 60 x 77 cm
Hyundai generators are supported in Australia with national parts and service backing.
