7kVA Gentech Petrol Workstation WS200-14-10HSR

The WS200-14-10HSR is a petrol workstation that runs four machines from one Honda GX390 engine: a single phase generator with a maximum output of 7kVA at 0.8 power factor, a 200 amp AC welder at a 60% duty cycle, a 14 CFM air compressor with a 50 L air tank and a 10 amp battery charger. Starting is by recoil.

Key features

• One Honda GX390 drives the generator, welder, compressor and charger, so there is one engine to fuel and maintain.
• The welder gives 200 amps of AC output at a 60% duty cycle, about six minutes of full-current welding in every ten.
• Air tools run from the 14 CFM compressor and its 50 L air tank.
• A built-in 10 amp battery charger brings flat batteries back up without a separate charger.
• The alternator is brushless, so there are no carbon brushes to wear out.
• An automatic decompressor reduces the effort of pulling the recoil starter.
• A centre point lift gives lifting equipment a single point to pick the unit up from.

The 6.1 L tank gives about 2.5 hours at 80% load, using about 2.44 L/h at that load. Noise is 69 dBA at 7 m. Output is through two 15 Amp plugs.

What it will run

The generator side has a rated output of 5.6kW. Within that figure it typically handles site lighting, a pump and power tools. A motor can draw several times its running load as it starts, so check the compliance plate on each appliance. Make sure each air tool's CFM demand sits within the compressor's 14 CFM. All four functions share one engine, so add up what you will use at the same time, or send us your load list and we will help with sizing.

The WS200-14-10HSR suits field service crews, fencing and rural contractors, plant maintenance teams and workshops that need welding, air, power and battery charging from one unit.

Key specifications

• Maximum output: 7kVA @ 0.8PF
• Welding output: Welder 200 Amp (AC), Duty Cycle 60%; Compressor 14 CFM, Air Tank Capacity 50 L; Battery Charger 10 Amp
• Engine: Honda GX390 (11.7 HP)
• Start type: Recoil
• Fuel: Unleaded/Petrol
• Fuel tank: 6.1 L
• Run time: Approx. 2.5 hrs @ 80% load; fuel consumption 2.44 L/hr @ 80% Load
• Noise level: 69 dBA @ 7m
• Outlets: 2 x 15 Amp plugs
• Phase / voltage: 1-Phase; 240 V
• Dimensions (L x W x H): 90 x 87 x 68 cm
• Weight: 105 kg
• Warranty: Generators 24 months; Honda GX engine 36 months.
• Rated output: 5600 W
• Frequency: 50 Hz
• Alternator: Brushless
• Auto decompressor: Yes
• Centre point lift: Yes

Gentech generators are backed Australia-wide with national parts and service support.
