2.5kVA Honda Petrol Generator GH2000

The GH2000 is a single phase petrol generator producing 2kW / 2.5kVA at 240V and 50Hz. Its engine is a Honda GX160, an overhead valve single cylinder unit running at 3000 rpm with recoil start. The alternator is an AC synchronous brushless type with Class H insulation, and a small roll frame surrounds the set.

Key features

• Two 10A 240V sockets are switched with thermal overload protection, so an overloaded circuit trips before it overheats.
• Recoil start has no battery to charge or go flat, which keeps starting simple.
• Harmonic distortion is below 5%, so the supply suits electronic equipment such as laptops and chargers alongside tools.
• The small roll frame protects the engine and alternator from knocks around a worksite.
• A brushless alternator has no brushes to wear, and Class H insulation is a high heat class for its windings.
• The Honda engine is covered by a 3 year limited warranty.

The 3.6 litre tank runs the set for 3.1 hours at full load or 5 hours at 60% load. Noise is 72 dB(A) at 7 m. Engine oil capacity is 0.6 litres.

What it will run

At 2kW the GH2000 can supply about 8.3A in total at 240V (2000W divided by 240V), shared across both sockets. Typically that suits site lighting, a drill, an angle grinder, a small compressor, a transfer pump and phone or laptop chargers, as long as the running total stays inside the rated output. Motors draw several times their running current at start, so start the biggest load first and add the rest afterwards. The compliance plate on each appliance gives its running and starting figures. Connecting to a building must go through an inlet and changeover switch installed by a licensed electrician. Send us your load list and we will help with sizing.

The GH2000 suits worksites, workshops, farm jobs and events, and can stand by for essential circuits at home when the grid drops.

Key specifications

• Maximum output: 2.5kVA / 2kW
• Engine: Honda GX160
• Phase: Single phase
• Fuel tank: 3.6 litres
• Run time: 3.1hr @ 100%, 5hrs @ 60% Load
• Noise level: 72 dB(A) @7m
• Weight: 35 kg
• Dimensions (L x W x H): 67 x 45 x 52 cm
• Engine type: Overhead valve, single cylinder
• Engine speed: 3000 rpm
• Starting: Recoil start
• Voltage and frequency: 240V, 50Hz
• Outlets: 2 x 10A 240V (switched with thermal overload)
• Frame: Small roll frame
• Alternator: AC synchronous brushless, Class H insulation, harmonic distortion less than 5%
• Engine oil capacity: 0.6 litres
• Engine warranty: 3 years limited

Part of the Honda range at Gen4Sale.
